I

n this chapter, we introduce the concept of the virtual machine. Virtual machines have

been developed for decades in various forms. They became known to normal developers

in 1995 when Sun Microsystem published the Java programming language and the associ￾ated Java virtual machine (JVM).

1.1 TYPES OF VIRTUAL MACHINES

Virtual machine is a computing system. The ultimate goal of a computing system is to exe￾cute programmed logics. The logics can be expressed at a very low level with all the details

of an actual computer, or at a very high level with scripting or markup language. From this

perspective, virtual machines can be broadly categorized into four types according to the

level of abstraction and scope of emulation.

Type 1. Full instruction set architecture (ISA) virtual machine provides a full computer

system’s ISA emulation or virtualization. Guest operating system and applications

can run on the top of the virtual machine as on an actual computer (e.g., VirtualBox,

QEMU, and XEN).

Type 2. Application Binary Interface (ABI) virtual machine provides a guest process

ABI emulation. Applications against that ABI can run in the process side by side

with other processes of native ABI applications (e.g., Intel’s IA-32 Execution Layer on

Itanium, Transmeta’s Code Morphing for X86 emulation, and Apple’s Rosetta trans￾lation layer for PowerPC emulation).

Type 3. Virtual ISA virtual machine provides a runtime engine so that applications

coded in the virtual ISA can execute on it. Virtual ISA usually defines a high level

and limited scope of ISA semantics, so it does not require the virtual machine to

4 ◾ Advanced Design and Implementation of Virtual Machines

emulate a full computer system (e.g., Sun Microsystem’s JVM, Microsoft’s Common

Language Runtime, and Parrot Foundation’s Parrot virtual machine).

Type 4. Language virtual machine provides a runtime engine that executes programs

expressed in a guest language. The programs are usually presented to the virtual

machine in source form of the guest language, without being fully compiled into

machine code beforehand. The runtime engine needs to interpret or translate the pro￾gram and also fulfill certain functionalities that are abstracted by the language such

as memory management (e.g., the runtime engines for Basic, Lisp, Tcl, and Ruby).

The boundaries between virtual machine types are not clear-cut. There are many virtual

machine designs crossing the boundaries. For example, a language virtual machine can

also employ the technique of a virtual ISA virtual machine by compiling the program into

a kind of virtual ISA and then executing the code on a virtual machine of that virtual ISA.

Still it is meaningful to categorize the virtual machine types so as to facilitate community

communications.

The first two types of virtual machines are of ISA or ABI emulation. Their goal is to run

existing guest operating systems or guest applications that are developed for ISA or ABI

other than the host native one. Sometimes, they are also called emulators.

The other two types of virtual machines are of language runtime engines whose goal is

to execute the logics programmed in the form of virtual ISA or guest language. In some

context, virtual ISA is considered a special kind of language; apart from that, there is no

essential difference between the two types of language runtime engines.

The topic of this book is the language runtime engines. The key phrase “virtual machine”

in the following chapters refers only to language runtime engine unless otherwise stated, and

“runtime engine” can be used interchangeably as “virtual machine.” “Runtime engine” is so

called because the services provided by the virtual machine are mostly only available at run￾time. As a comparison, in the traditional setting of “compiler + operating system,” applica￾tions are compiled statically by a compiler before its distribution. For the same reason, some

people use “runtime system” to refer to the services available at runtime that enables a soft￾ware to execute.

1.2 WHY VIRTUAL MACHINE?

Virtual machines are indispensable to modern programming. They help (computer) secu￾rity, (programming) productivity, and (application) portability.

Virtual machines are necessary for safe languages. Safe language is a very broad term

here and mainly refers to the language that has properties of memory safety, operation

safety, and control safety. With a safe language, it is easier to catch program bugs or execu￾tion errors early and safely.

1. Memory safety ensures that a certain type of data in the memory always follow the

restrictions of that type. For example, a variable of pointer type never holds an illegal

pointer; an array never has elements out of bound.

Introduction of the Virtual Machine   ◾   5

2. Operation safety ensures that the operations on a certain type of data always follow

the restrictions of that type. For example, a variable of pointer type does not allow

arbitrary arithmetic operations on it.

3. Control safety ensures that the flow of code execution never reach any point that

either gets stuck or goes wild, for example, jump to a malicious code segment. Control

safety can be considered a special kind of operation safety.

Almost all modern languages such as Java, C#, Java bytecode, Microsoft Intermediate

Language, and JavaScript are safe languages, although their individual safety extents can

be different.

To support a safe language, a virtual machine is necessary because the safe language

itself cannot fulfill all the safety requirements. For example, the program should not

directly allocate a piece of memory that has no type associated; it needs the assistance of a

virtual machine to provide the typed memory for it, such as a certain type of object.

Virtual machine provides “management” on the code and data of the safe language.

Therefore, the code and data sometimes are called “managed code” and “managed data.” In

turn, the virtual machine is sometimes also called “managed runtime,” “managed system,”

or “managed execution environment.”

Since it is harder for a program written in a safe language to be attacked by a malicious

code, virtual machine is sometimes employed in security sandboxing. One example is the

Google Chrome NaCl technique.

Since a safe language can catch program bugs or execution errors early and safely at the

compile-time or runtime, it largely improves developer’s productivity.

Virtual machine helps portability in the sense that the virtual ISA or guest language is

not tied to any specific native ISA or ABI definition. Applications in virtual ISA or guest

language can run on any systems that have the virtual machine deployed. Another per￾spective of portability is that many applications written in other programming languages

choose to compile to the virtual ISA or guest language rather than the machine native code

directly because then they can benefit from the virtual machine’s various properties such

as portability, performance, and security.

Virtual machine can be designed to support unsafe languages too, but that is only an

extension rather than the original design purpose. An unsafe language is used to facilitate

the safe language to access low-level resources or to reuse legacy code written in the unsafe

language.

1.3 VIRTUAL MACHINE EXAMPLES

A virtual machine, as the runtime engine of the guest language, can be categorized accord￾ing to the implementation of its execution engine. An execution engine is the component

that expresses the applications’ operational semantics. The two basic execution engines are

interpretation and compilation.

With interpretation, there is usually no machine code generated from the applica￾tion code. The application code is parsed by an interpreter into certain form of internal

6 ◾ Advanced Design and Implementation of Virtual Machines

representation that can express the program’s semantics, based on the syntax specification

of the guest language, and then the execution engine manipulates the program’s states

(i.e., executes the code) by following the operational semantics of the internal representation.

With compilation, the application code is also parsed syntactically, but is then translated into the machine code according to the operational semantics. Later the machine

code is executed by the host machine through which application states are manipulated.

There is no strict boundary between the two types of virtual machines. It is quite common for the interpreter-based virtual machine to compile the application code in one guest

language into the code of another guest language and then interpret it. The code of another

guest language is usually called “intermediate representation” (IR) in the compiler community. It is also common for a virtual machine to execute a piece of the application code

with interpretation and then do the next piece with compilation.

A virtual machine can be implemented in software or hardware or both combined.

Some hardware is designed to directly execute the virtual ISA instructions, which is no

longer a virtual machine since the virtual ISA is no longer virtual. Conventionally, it is still

called virtual machine but implemented in hardware.

Since almost all modern programming languages rely on a virtual machine, it is no surprise that a user probably cannot live without one virtual machine or two. The following

are some of the examples.

1.3.1 JavaScript Engine

The most commonly used virtual machine can be the one for JavaScript in web browsers.

For example, Google Chrome has V8 JavaScript engine; Mozilla Firefox has SpiderMonkey;

Apple Safari has JavaScriptCore; and Microsoft Internet Explorer has Chakra. Each of

them has been developed independently and adopted different techniques to accelerate

JavaScript code execution.

SpiderMonkey is the name of the world’s first JavaScript engine. Firefox has evolved it

from a purely interpretation-based virtual machine into a compiler-based engine through

projects such as TraceMonkey, JägerMonkey, and IonMonkey. The current version of

SpiderMonkey as of year 2015 translates the JavaScript code into its IR in the form of

bytecode and then invokes IonMonkey to compile the bytecode into the machine code.

Internally, IonMonkey, as a traditional static compiler, builds up a control flow graph

(CFG) with a static single assignment (SSA) representation so as to make advanced optimizations possible.

1.3.2 Perl Engine

Another kind of widely used virtual machines are for traditional scripting languages such

as Unix shell, Windows PowerShell, Perl, Python, and Ruby. They are called scripting languages because they are commonly used in an interactive way of “type and run,” and with

a fast development turnaround. Interactive execution means the program executes one line

of code then waits for the programmer’s input to execute the next line of code. Scripting

languages are also commonly used to batch or automate the execution of a sequence of

tasks.
